Family Datasheet
Product Datasheet
FDS73600v0
| Electrical Data | |
| Voltage (V) | 220-240V |
| Frequency (Hz) | 50 |
| Power Factor (λ) | >0.5 |
| Product Data | |
| Product Wattage (W) | 2 |
| Light Source | Integrated LED-4000 |
| Colour Render Index (Ra) | > Ra80 |
| Colour | White (WH12), Black (BK12), Brushed Nickel (NI52) |
| Protection Class | CL II |
| Colour Consistency (SDCM) | ≤6 |
| Operating Temperature | -30°C to +40°C |
| Switching Cycles (times) | 100000 |
| Weight (g) | 85.3 |
| Application | Retails, Hotels, Kitchens, Offices, Restaurants, Under cabinet |
| Performance Data | |
| IP Rating | IP20 |
| Product Dimensions | |
| Diameter (mm) | 64 |
| Height (mm) | 21 |
