Family Datasheet
     Product Datasheet
Model no.:

FFL72000v0-ps

Electrical Data
Voltage (V) 220-240V
Frequency (Hz) 50/60
Input Current (mA) 136
Power Factor (λ) >0.9
Product Data
Product Wattage (W) 31
Light Source Integrated LED-3000
Beam Angle (°) 110
Colour Render Index (Ra) Ra80
Protection Class CL I
Colour Consistency (SDCM) 6
Dimmable no
Energy Label F
Operating Temperature -30°C to +50°C
Ambient Temperature Range (Ta) 50
Switching Cycles (times) 100000
Application Billboards, Façade, Gate areas, Industrial Areas, Warehouses
Performance Data
Luminous Flux (lm) 2550
Rated Useful Luminous Flux (lm) 2730
Luminous Efficacy (lm/W) 82
Rated Life (hrs) 30,000hrs L70B50@Ta25°C
IP Rating IP54/IP54
Product Dimensions
Length (mm) 196
Width (mm) 160
Height (mm) 45
Remarks
Open wire version
