Family Datasheet
     Product Datasheet
Model no.:

FFL71900v0-ps

Electrical Data
Voltage (V) 220-240V
Frequency (Hz) 50/60
Input Current (mA) 91
Power Factor (λ) >0.9
Product Data
Product Wattage (W) 21
Light Source Integrated LED-3000
Beam Angle (°) 110
Colour Render Index (Ra) Ra80
Protection Class CL I
Colour Consistency (SDCM) 6
Dimmable no
Energy Label F
Operating Temperature -30°C to +50°C
Ambient Temperature Range (Ta) 50
Switching Cycles (times) 100000
Application Billboards, Façade, Gate areas, Industrial Areas, Warehouses
Performance Data
Luminous Flux (lm) 1700
Luminous Efficacy (lm/W) 81
Rated Life (hrs) 30,000hrs L70B50@Ta25°C
IP Rating IP54/IP54
Product Dimensions
Length (mm) 163
Width (mm) 121
Height (mm) 45
Remarks
Open wire version
