FIB76100v0-ps
| Electrical Data | |
| Voltage (V) | 220-240V |
| Frequency (Hz) | 50 |
| Power Factor (λ) | 0.5 |
| Product Data | |
| Product Wattage (W) | 8.2 |
| Light Source | Integrated LED-4000 |
| Colour Render Index (Ra) | > Ra80 |
| Colour | White (WH11), Silver (SV12) |
| Protection Class | CL II |
| Colour Consistency (SDCM) | ≤6 |
| Operating Temperature | -30°C to +40°C |
| Switching Cycles (times) | 100000 |
| Weight (g) | 173 |
| Application | Kitchens, Staircases, Under cabinet, Wardrobes |
| Performance Data | |
| Luminous Efficacy (lm/W) | 100 |
| IP Rating | IP20/IP20 |
| Product Dimensions | |
| Length (mm) | 550 |
| Width (mm) | 58 |
| Height (mm) | 24 |
