FDS71900v0-dm/sc
| Electrical Data | |
| Voltage (V) | 220-240V |
| Frequency (Hz) | 50 |
| Input Current (mA) | 27 |
| Power Factor (λ) | >0.8 |
| Total Harmonic Distortion | 54.5% |
| Product Data | |
| Product Wattage (W) | 5 |
| Light Source | Integrated LED-3000/4000 |
| Beam Angle (°) | 36 |
| Colour Render Index (Ra) | Ra80 |
| Colour | White (WH12), Chrome (CH53), Brushed Nickel (NI52) |
| Protection Class | CL II |
| Colour Consistency (SDCM) | 6 |
| Dimmable | Yes |
| Operating Temperature | -20°C to +40°C |
| Ambient Temperature Range (Ta) | 25 |
| Switching Cycles (times) | 100000 |
| Weight (g) | 176 |
| Application | Corridors, Hotels, Kitchens, Offices, Restaurants |
| Performance Data | |
| Total Luminous Flux (lm) | 400/420 |
| Luminous Flux (lm) | 400/420 |
| Rated Useful Luminous Flux (lm) | 400/420 |
| Rated Life (hrs) | 30,000hrs L70B50@Ta25°C |
| IP Rating | IP20/IP65 |
| Product Dimensions | |
| Diameter (mm) | 85 |
| Height (mm) | 70 |
