FDS73100v0-dm
| Electrical Data | |
| Voltage (V) | 220-240V |
| Frequency (Hz) | 50 |
| Power Factor (λ) | >0.8 |
| Product Data | |
| Product Wattage (W) | 5.5 |
| Light Source | Integrated LED-4000 |
| Colour Render Index (Ra) | Ra80 |
| Protection Class | CL II |
| Colour Consistency (SDCM) | ≤6 |
| Operating Temperature | -30°C to +40°C |
| Switching Cycles (times) | 100000 |
| Weight (g) | 160 |
| Application | Conference Rooms, Corridors, Hotels, Offices, Restaurants, Shops |
| Performance Data | |
| IP Rating | IP20/IP65 |
| Product Dimensions | |
| Diameter (mm) | 83 |
| Height (mm) | 51 |
Technologies
-
Compatible with the widest range of existing dimmers, whether they are leading-edge or trailing edge dimmers, with enhanced dimming range of 100% down to 5%.
