FDS72300v0-dm-db-sc-36D
FDS72300v0-dm-db-sc-60D
Family Datasheet
Product Datasheet
FDS72300v0-dm/db/sc
| Electrical Data | |
| Voltage (V) | 220-240V |
| Frequency (Hz) | 50/60 |
| Input Current (mA) | 42 |
| Power Factor (λ) | >0.9 |
| Product Data | |
| Product Wattage (W) | 7.5 |
| Light Source | Integrated LED-2800/4000 |
| Beam Angle (°) | 36/60 |
| Colour Temperature (K) | 2800, 4000 |
| Colour Render Index (Ra) | > Ra80 |
| Colour | White (WH26), Matt Black (BK22), Chrome (CH52), Gold (GD53), Brushed Nickel (NI53) |
| Protection Class | CL I |
| Colour Consistency (SDCM) | SDCM <4 |
| Operating Temperature | -30°C to +40°C |
| Switching Cycles (times) | 100000 |
| Weight (g) | 249 |
| Application | Retails, Bathrooms, Hotels, Kitchens, Offices, Restaurants |
| Performance Data | |
| Luminous Flux (lm) | 600/650 |
| Luminous Efficacy (lm/W) | 80/87 |
| IP Rating | IP20/IP54 |
| Product Dimensions | |
| Diameter (mm) | 86 |
| Height (mm) | 73 |
Remarks
|
|
Technologies
-
The innovative Dual Beam Technology empowers commercial users to have two beam angles in one single lamp/luminaire. It offers high flexibility of changing the beam angles onsite for different application requirements.
