Photometric Diagram
Lux-cone Diagram
     Family Datasheet
     Product Datasheet
Model no.:

F62300RC-w/ru

Electrical Data
Voltage (V) DC 15-19V
Power Factor (λ) 1
Product Data
Product Wattage (W) 6
Light Source Integrated LED-[3000-1800]
Colour Render Index (Ra) Ra97
Protection Class CL III
Colour Consistency (SDCM) ≤6
Operating Temperature -30°C to +40°C
Weight (g) 116
Application Bathrooms, Corridors, Display Shelves, Hotels, Kitchen Cabinets and Counters, Offices, Shopping Malls, Shops, Study Rooms, Wardrobes, Workstations
Performance Data
Luminous Flux (lm) 500
IP Rating IP20/IP44
Product Dimensions
Diameter (mm) 80
Height (mm) 30
