Photometric Diagram
Lux-cone Diagram
     Family Datasheet
     Product Datasheet
Model no.:

F53500RCv2

Electrical Data
Voltage (V) DC 16-21V
Power Factor (λ) 1
Product Data
Product Wattage (W) 9
Light Source Integrated LED-4000
Colour Render Index (Ra) Ra80
Protection Class CL III
Colour Consistency (SDCM) ≤6
Operating Temperature -30°C to +40°C
Weight (g) 117
Application Bathrooms, Corridors, Display Shelves, Hotels, Kitchen Cabinets and Counters, Offices, Shopping Malls, Shops, Study Rooms, Wardrobes, Workstations
Performance Data
Luminous Flux (lm) 900
IP Rating IP20/IP44
Product Dimensions
Diameter (mm) 80
Height (mm) 30
