FDM71700v0
| Electrical Data | |
| Voltage (V) | 220-240V |
| Frequency (Hz) | 50/60 Hz |
| Power Factor (λ) | >0.5 |
| Product Data | |
| Product Wattage (W) | 9 |
| Light Source | Integrated LED-6500 |
| Colour Render Index (Ra) | Ra80 |
| Protection Class | CL II |
| Colour Consistency (SDCM) | SDCM ≤ 6 |
| Operating Temperature | -30°C to +40°C |
| Switching Cycles (times) | 100000 |
| Weight (g) | 80 |
| Application | Retails, Hotels, Kitchens, Offices, Restaurants |
| Performance Data | |
| Luminous Flux (lm) | 720 |
| Luminous Efficacy (lm/W) | 80 |
| IP Rating | IP20/IP20 |
| Product Dimensions | |
| Diameter (mm) | 125 |
| Height (mm) | 30 |
