IES File
Family Datasheet
Product Datasheet
FDL71600v0-ds/sc
| Electrical Data | |
| Voltage (V) | 220-240V |
| Frequency (Hz) | 50/60 |
| Input Current (mA) | 127/100 |
| Power Factor (λ) | >0.9 |
| Product Data | |
| Product Wattage (W) | 23/18 |
| Light Source | Integrated LED-3000/4000 |
| Beam Angle (°) | 100 |
| Colour Render Index (Ra) | > Ra80 |
| Protection Class | CL II |
| Colour Consistency (SDCM) | ≤4 |
| Energy Label | A+ |
| Operating Temperature | -30°C to +40°C |
| Switching Cycles (times) | 100,000 |
| Weight (g) | 620 |
| Application | Retails, Bathrooms, Hotels, Kitchens, Offices, Restaurants |
| Performance Data | |
| Total Luminous Flux (lm) | 2140/1670 @3000K 2300/1800 @4000K |
| Luminous Flux (lm) | 2140/1670 @3000K 2300/1800 @4000K |
| Luminous Efficacy (lm/W) | 93/93@3000K 100/100@4000K |
| IP Rating | IP20/IP54 |
| Product Dimensions | |
| Diameter (mm) | 225 |
| Height (mm) | 97 |
