Family Datasheet
     Product Datasheet
Model no.:

FDM72300v0

Electrical Data
Voltage (V) 220-240V
Frequency (Hz) 50/60
Input Current (mA) 32
Power Factor (λ) >0.9
Product Data
Product Wattage (W) 7
Light Source Integrated LED-4000
Beam Angle (°) 120
Colour Render Index (Ra) Ra80
Protection Class CL II
Colour Consistency (SDCM) 6
Dimmable no
Energy Label G
Operating Temperature -30°C to +50°C
Ambient Temperature Range (Ta) 50
Switching Cycles (times) 100000
Application Retails, Bathrooms, Hotels, Kitchens, Offices, Restaurants
Performance Data
Luminous Flux (lm) 560
Rated Useful Luminous Flux (lm) 590
Luminous Efficacy (lm/W) 80
Rated Life (hrs) 30,000hrs L70B50@Ta25°C
IP Rating IP20/IP40
Product Dimensions
Diameter (mm) 115
Height (mm) 31
Remarks
可外接Emergency Module 作3小时应急照明
