Family Datasheet
     Product Datasheet
Model no.:


Electrical Data
Voltage (V) 220-240V
Frequency (Hz) 50/60
Input Current (mA) 290
Power Factor (λ) 0.9
Product Data
Product Wattage (W) 50
Light Source Integrated LED-4000
Beam Angle (°) 120
Colour Render Index (Ra) Ra80
Protection Class CL II
Colour Consistency (SDCM) 6
Dimmable yes
Operating Temperature -25°C to +40°C
Ambient Temperature Range (Ta) 25
Switching Cycles (times) 100000
Weight (g) 1290
Application Car parks, Underground Areas, Warehouses, Workshops
Performance Data
Luminous Flux (lm) 6000
Rated Useful Luminous Flux (lm) 6890
Luminous Efficacy (lm/W) 120
Rated Life (hrs) 50,000hrs L80B50@Ta25°C
IP Rating IP66/IP66
Product Dimensions
Length (mm) 1510
Width (mm) 55
Height (mm) 55
End cap pack with film,可选配ECA32WP
