Photometric Diagram
Lux-cone Diagram
     Family Datasheet
     Product Datasheet
Model no.:


Electrical Data
Voltage (V) 220-240V
Frequency (Hz) 50/60
Input Current (mA) 100
Power Factor (λ) 0.9
Product Data
Product Wattage (W) 17
Light Source Integrated LED-4000
Beam Angle (°) 120
Colour Render Index (Ra) Ra80
Protection Class CL II
Colour Consistency (SDCM) 6
Dimmable no
Operating Temperature -30°C to +50°C
Ambient Temperature Range (Ta) 25
Switching Cycles (times) 100000
Weight (g) 500
Application Car parks, Underground Areas, Warehouses, Workshops
Performance Data
Luminous Flux (lm) 2000
Rated Useful Luminous Flux (lm) 2300
Luminous Efficacy (lm/W) 118
Rated Life (hrs) 50,000hrs L80B50@Ta25°C
IP Rating IP66/IP66
Product Dimensions
Length (mm) 610
Width (mm) 55
Height (mm) 55
End cap pack with film,可选配ECA32WP
