Please open the web page in browser.DINO 2 Waterproof Batten (Integrated) - Opal Prismatic Diffuser Options - Permanent Live
-
IES File -
Control Gear (PDF) -
Containing Product (PDF)
-
Light Source (PDF)
Integrated LED Luminaire
FOB61500v1-pl
Family Datasheet
Product Datasheet
FOB61500v1-pl
| Electrical Data | |
| Voltage (V) | 220-240V |
| Frequency (Hz) | 50/60 |
| Input Current (mA) | 174 |
| Power Factor (λ) | >0.9 |
| Product Data | |
| Product Wattage (W) | 36 |
| Light Source | Integrated LED-4000 |
| Beam Angle (°) | 160 |
| Colour Temperature (K) | Warmwhite (3000K), Coolwhite (4000K) |
| Colour Render Index (Ra) | Ra80 |
| Colour | Silver (SV16) |
| Materials | Polycarbonate with opal prismatic diffuser |
| Protection Class | CL II |
| Colour Consistency (SDCM) | 6 |
| Dimmable | no |
| Operating Temperature | -30°C to +50°C |
| Ambient Temperature Range (Ta) | 25 |
| Switching Cycles (times) | 100000 |
| Weight (g) | 902 |
| Application | Car parks, Underground Areas, Warehouses, Workshops |
| Performance Data | |
| Luminous Flux (lm) | 4930 |
| Rated Useful Luminous Flux (lm) | 4930 |
| Luminous Flux (lm) | 4150 [3000K], 1000 [4000K] |
| Luminous Efficacy (lm/W) | 100 [3000K], 104 [4000K] |
| Rated Life (hrs) | 50000 hrs at L80, B10 at Ta 25°C |
| Rated Life (hrs) | 50,000hrs L80B10@Ta25°C |
| IP Rating | IP66/IP66 |
| Product Dimensions | |
| Length (mm) | 1323 |
| Width (mm) | 60 |
| Height (mm) | 54 |
|
Remarks DC Input Voltage:200-250VDC,可匹配LA11156 |
|
