Family Datasheet
     Product Datasheet
Model no.:

FOB70900v1-pl

Electrical Data
Voltage (V) 220-240V
Frequency (Hz) 50/60
Input Current (mA) 256
Power Factor (λ) >0.9
Product Data
Product Wattage (W) 53
Light Source Integrated LED-4000
Beam Angle (°) 160
Colour Render Index (Ra) Ra80
Protection Class CL II
Colour Consistency (SDCM) 6
Dimmable no
Operating Temperature -30°C to +50°C
Ambient Temperature Range (Ta) 25
Switching Cycles (times) 100000
Application Animal House(poultry, cow, pig, etc.), Farm, Greenhouse
Performance Data
Luminous Flux (lm) 6500
Rated Useful Luminous Flux (lm) 7460
Luminous Efficacy (lm/W) 123
Rated Life (hrs) 50,000hrs L80B10@Ta25°C
IP Rating IP66/IP66
Product Dimensions
Length (mm) 1623
Width (mm) 60
Height (mm) 54
Remarks
DC Input Voltage:200-250VDC Glass-Fiber-Reinforced Nylon Endcap/PMMA Diffuser 4 pole terminal block: L1/L2/E/N L1:permanent live
