Please open the web page in browser.Brilliant Tone-GX53 5W 30D 5500K
GX53
IES File
Family Datasheet
Product Datasheet
LR1305-30D-GX53-5500K-230V
| Electrical Data | |
| Voltage (V) | 220-240V |
| Frequency (Hz) | 50/60 |
| Power Factor (λ) | > 0.4 |
| Starting Time (sec) | < 0.5 s |
| Warm-up Time Up to 100% of the Full Light Output (sec) | Instant full light |
| Product Data | |
| Lamp Base | GX53 |
| Product Wattage (W) | 5 |
| Reflector | GX53 |
| Beam Angle (°) | 30 |
| Colour Temperature (K) | Daylight (5500K) |
| Colour Render Index (Ra) | Ra82 |
| Colour Consistency (SDCM) | SDCM <6 |
| Dimmable | No |
| Energy Label | A+ |
| Operating Temperature | -30°C to +40°C |
| Switching Cycles (times) | >1000000 |
| Mercury Content (mg) | N/A |
| Weight (g) | 82 |
| Application | Retails, Hospitality, Residential |
| Performance Data | |
| Max. Luminous Intensity (cd) | 850 |
| Total Luminous Flux (lm) | 350 |
| Rated Life (hrs) | 30000 |
| Lumen Maintenance at the End of Lamp Life (%) | ≥90 |
| Product Dimensions | |
| Diameter (mm) | 75 |
| Length (mm) | 25 |
Technologies
-
Using patented Thermal Conductive Highway™ technology and a unique design of ‘heat drain’ across the reflector to dissipate heat efficiently from the dual axial LED to prevent deterioration of the chips and other components.
