Please open the web page in browser.PAR20 8W E26 30D 2800K-127V
LED BR20, BR30, BR40
IES File
LR0308-50H30D-E26-2800K-127V
| Electrical Data | |
| Voltage (V) | 127V |
| Frequency (Hz) | 50/60 |
| Product Data | |
| Lamp Base | E26 |
| Product Wattage (W) | 8 |
| Reflector | PAR20 |
| Beam Angle (°) | 30 |
| Colour Temperature (K) | Warmwhite (2800K) |
| Colour Render Index (Ra) | Ra85 |
| Dimmable | No |
| Operating Temperature | -30°C to +40°C |
| Mercury Content (mg) | N/A |
| Weight (g) | 93 |
| Application | Hospitality |
| Performance Data | |
| Max. Luminous Intensity (cd) | 1600 |
| Total Luminous Flux (lm) | 336 |
| Rated Life (hrs) | 25000 |
| Standard Pack | 60 (10) |
| Product Dimensions | |
| Diameter (mm) | 65 |
| Length (mm) | 93 |
Technologies
-
Using patented Thermal Conductive Highway™ technology and a unique design of ‘heat drain’ across the reflector to dissipate heat efficiently from the dual axial LED to prevent deterioration of the chips and other components.
