Dim-to-Warm-MR16 6W GU5.3 36D 2800K

MR16

Family Datasheet

Product Datasheet

Product Code:

Electrical Data
Voltage (V)	DC 18V
Frequency (Hz)	50/60
Current (mA)	350
Product Data
Lamp Base	GU5.3
Product Wattage (W)	6
Reflector	MR16
Beam Angle (°)	36
Colour Temperature (K)	Warmwhite (2800K)
Colour Render Index (Ra)	Ra82
Dimmable	100-1%
Energy Label	A
Operating Temperature	-30°C to +40°C
Mercury Content (mg)	N/A
Weight (g)	51
Application	Retails, Hospitality
Performance Data
Max. Luminous Intensity (cd)	1100
Total Luminous Flux (lm)	500
Luminous Flux in 90° cone (lm)	330
Rated Life (hrs)	40000
Product Dimensions
Diameter (mm)	50
Length (mm)	45
Remarks Capable of linear dimming from 100% to 1% when connected to a LED constant current reduction converter with output current of 350mA and voltage DC 18V and DC1-10V dimmer. If the lamps are connected to a MEGAMAN^® U-DIM™ LED converter LD0208x1d-C350, the dimming range is 100% to 5% and compatible with both leading-edge and trailing edge dimmers. The rated lamp life, rated luminous flux in 90° cone, total luminous flux, rated beam angle and rated wattage are equivalent to their nominal values shown on product packaging. There is no measurable output from 180nm to 380nm, so the chart shows only 380nm to 800nm.

Following exactly the dimming curve of familiar incandescent and halogen lamps, the LED lamps could simultaneously emit a warmer light when they are dimmed from 100% to 5%.
Using patented Thermal Conductive Highway™ technology and a unique design of ‘heat drain’ across the reflector to dissipate heat efficiently from the dual axial LED to prevent deterioration of the chips and other components.

Indoor
