Please open the web page in browser.MR16
-
Discontinued
Family Datasheet
Product Datasheet
ER203080/dm-HRv00-NF+GU5.3+828+AC012
| Electrical Data | |
| Voltage (V) | AC 12V |
| Power Factor (λ) | > 0.9 |
| Starting Time (sec) | < 0.5 s |
| Warm-up Time Up to 100% of the Full Light Output (sec) | Instant full light |
| Product Data | |
| Lamp Base | GU5.3 |
| Product Wattage (W) | 8 |
| Equivalent Wattage (W) | 46 |
| Reflector | MR16 |
| Beam Angle (°) | 24 |
| Colour Temperature (K) | Warmwhite (2800K) |
| Colour Render Index (Ra) | Ra80 |
| Dimmable | 100-10% |
| Operating Temperature | -30°C to +40°C |
| Switching Cycles (times) | >1000000 |
| Mercury Content (mg) | No |
| Weight (g) | 55 |
| Application | Retails, Hospitality |
| Performance Data | |
| Max. Luminous Intensity (cd) | 3000 |
| Total Luminous Flux (lm) | 600 |
| Rated Life (hrs) | 25000 |
| Lumen Maintenance at the End of Lamp Life (%) | ≥90 |
| Product Dimensions | |
| Diameter (mm) | 50 |
| Length (mm) | 49 |
|
Remarks The rated lamp life, rated luminous flux in 90° cone, total luminous flux, rated beam angle and rated wattage are equivalent to their nominal values shown on product packaging. |
|
Technologies
-
Being able to adjust your LEDs with wide selection of dimming range from 100% to 10% or 20% for perfect atmosphere and/or scene setting – warm and bright, dim and cozy.
