Please open the web page in browser.50W/6.5W GU5.3 650lm 2700K Ra80 Dimmable
MR16
IES File
Technical Document (PDF)
Family Datasheet
Product Datasheet
ER200065/dm-HRv00-WF+GU5.3+827+C0350
| Electrical Data | |
| Voltage (V) | DC 16-20V |
| Current (mA) | 350 |
| Power Factor (λ) | ≥ 0.50 |
| Starting Time (sec) | < 0.5 s |
| Warm-up Time Up to 60% of the Full Light Output (sec) | Instant |
| Product Data | |
| Lamp Base | GU5.3 |
| Product Wattage (W) | 6.5 |
| Equivalent Wattage (W) | 50 |
| Colour Temperature (K) | 2700 |
| Colour Render Index (Ra) | Ra80 |
| Colour Consistency (SDCM) | 6 |
| Dimmable | 100-1% |
| Operating Temperature | -30°C to +45°C |
| Switching Cycles (times) | > 100000 |
| Weight (g) | 45 |
| Application | Art Galleries, Gardens, Hotels, Retail Displays, Showcase Displays |
| Performance Data | |
| Max. Luminous Intensity (cd) | 1800 |
| Luminous Flux in 90° cone (lm) | 650 |
| Luminous Efficacy (lm/W) | 108 |
| Rated Life (hrs) | 35000 |
| Product Dimensions | |
| Diameter (mm) | 50 |
| Width (mm) | 50 |
| Height (mm) | 46 |
Technologies
-
Being able to adjust your LEDs with wide selection of dimming range from 100% to 10% or 20% for perfect atmosphere and/or scene setting – warm and bright, dim and cozy.
