PERFECT WHITE-AR111 12W G53 24D 3000K

AR111

Spectral Power Distribution

Family Datasheet

Product Datasheet

Product Code:

Electrical Data
Voltage (V)	AC 12V
Frequency (Hz)	50/60
Product Data
Lamp Base	G53
Product Wattage (W)	12
Equivalent Wattage (W)	75
Reflector	AR111
Beam Angle (°)	24
Colour Temperature (K)	Warmwhite (3000K)
Colour Render Index (Ra)	Ra82
Dimmable	100-10%
Energy Label	A
Operating Temperature	-30°C to +40°C
Mercury Content (mg)	N/A
Weight (g)	230
Application	Retails, Hospitality
Performance Data
Max. Luminous Intensity (cd)	4200
Total Luminous Flux (lm)	700
Luminous Flux in 90° cone (lm)	560
Rated Life (hrs)	35000
Product Dimensions
Diameter (mm)	111
Length (mm)	58
Remarks The rated life is declared based on an enclosed environment (the most severe situation). Extended life up to 40,000 hours is still possible when the lamp is used in more open fixtures. The rated lamp life, rated luminous flux in 90° cone, total luminous flux, rated beam angle and rated wattage are equivalent to their nominal values shown on product packaging. There is no measurable output from 180nm to 380nm, so the chart shows only 380nm to 800nm.

Being able to adjust your LEDs with wide selection of dimming range from 100% to 10% or 20% for perfect atmosphere and/or scene setting – warm and bright, dim and cozy.
Offering retailers a distinct advantage to enhance textiles by bringing whites to life while still offering superb efficacy and energy efficiency, compared to traditional light sources.
Using patented Thermal Conductive Highway™ technology and a unique design of ‘heat drain’ across the reflector to dissipate heat efficiently from the dual axial LED to prevent deterioration of the chips and other components.

Indoor
