Strip 11.5W 4000K

Smart Series

Spectral Power Distribution

Specification Sheet

Product Code:

Electrical Data
Voltage (V)	DC 24V
Frequency (Hz)	N/A
Constant Current (mA)	480
Product Data
Lamp Base	N/A
Product Wattage (W)	11.5
Colour Temperature (K)	Coolwhite (4000K)
Colour Render Index (Ra)	Ra85
Dimmable	Yes
Energy Label	A++
Operating Temperature	-30°C to +40°C
Mercury Content (mg)	N/A
Weight (g)	111
Application	Retail, Hospitality, Residential
Performance Data
Total Luminous Flux (lm)	600
Rated Life (hrs)	30000
IP Rating	IP20
Product Dimensions
Length (mm)	910
Width (mm)	8
Height (mm)	13
Remarks Capable of dimming when working with a pulse width modulation (PWM) dimmer; dimming performance depends on the specification and quality of the PWM dimmer. The rated wattage, rated lamp life and rated luminous flux are equivalent to their nominal values, which show on the product packaging.
