35W/3W GU9 400lm 2700K Ra80 Dimmable



Spectral Power Distribution
Spectral Power Distribution
     Family Datasheet
     Product Datasheet
Product Code:


Electrical Data
Voltage (V) 220-240V
Frequency (Hz) 50/60 Hz
Power Factor (λ) ≥ 0.60
Starting Time (sec) < 0.5 s
Warm-up Time Up to 60% of the Full Light Output (sec) Instant
Product Data
Lamp Base GU9
Product Wattage (W) 3
Equivalent Wattage (W) 35
Colour Temperature (K) 2700
Colour Render Index (Ra) Ra80
Colour Consistency (SDCM) 6
Dimmable 100-10%
Operating Temperature -30°C to +40°C
Switching Cycles (times) > 100000
Weight (g) 13
Application Indoor Decorative, Display Cabinets, Showcase Displays, Showrooms, Wall Lamps
Performance Data
Total Luminous Flux (lm) 400
Luminous Efficacy (lm/W) 133
Rated Life (hrs) 25000
Product Dimensions
Diameter (mm) 18
Width (mm) 18
Height (mm) 56
