G4 2.5W 2800K

LED G4

     Specification Sheet
Product Code:

EU200025-CSv00-G4-828-AC012

Electrical Data
Voltage (V) AC 12V
Power Factor (λ) >0.6
Starting Time (sec) <0.5
Warm-up Time Up to 100% of the Full Light Output (sec) Instant full light
Product Data
Lamp Base G4
Product Wattage (W) 2.5
Equivalent Wattage (W) 25
Colour Temperature (K) Warmwhite (2800K)
Colour Render Index (Ra) Ra80
Colour Consistency (SDCM) ≤6
Operating Temperature -30°C to +40°C
Switching Cycles (times) >1,000,000
Mercury Content (mg) N/A
Weight (g) 6
Application Hospitality, Residential
Performance Data
Total Luminous Flux (lm) 250
Rated Life (hrs) 15000
Lumen Maintenance at the End of Lamp Life (%) ≥70
Product Dimensions
Diameter (mm) 13
Length (mm) 39
Width (mm) N/A
Height (mm) N/A
Remarks
The rated wattage, rated lamp life and rated luminous flux are equivalent to their nominal values, which show on the product packaging.
