T100, T120

E





Spectral Power Distribution
Spectral Power Distribution
     Family Datasheet
     Product Datasheet
Product Code:

LG277340-OPv00+E27+865+V0240

Electrical Data
Voltage (V) 220-240V
Frequency (Hz) 50/60 Hz
Current (mA) 156
Power Factor (λ) ≥ 0.95
Starting Time (sec) < 0.5 s
Warm-up Time Up to 60% of the Full Light Output (sec) Instant
Total Harmonic Distortion .1
Product Data
Lamp Base E27
Product Wattage (W) 34
Equivalent Wattage (W) 200
Colour Temperature (K) 6500
Colour Render Index (Ra) Ra80
Colour Consistency (SDCM) 6
Dimmable No
Operating Temperature -30°C to +45°C
Maximum Casing Temperature (Tc) 100℃
Switching Cycles (times) > 100000
Weight (g) 170
Application Commercial Areas, Market stalls, Public area, Retail shops, Workshops
Performance Data
Luminous Efficacy (lm/W) 118
Rated Life (hrs) 15000
Product Dimensions
Diameter (mm) 118
Width (mm) 118
Height (mm) 178
